Hydraulic Quick Couplings > Series PD Diagnostic Hydraulic couplings
Materials:
Coupling:Steel(zinc chromate plating)
Nipple:Hardened steel(zinc chromate plating)
Features:
■Nipples meet or exceed SAE J 1502 and ISO 15171-1 design and performance specification Technical features
■Diagnostic couplings provide easily accessible test points for performance testing of hydraulic and pneumatic systems。
■A safety sleeve lock prevents accidental disconnection. Push-to-connect operation allows one hand operation when connecting the coupling.
■Flush-faced poppet for a minimal air inclusion when connecting ,minimal fluid loss during disconnection and for an easy cleaning.
■NBR (Nitrile) as standard. Other seal materials FKM (VitonTM), EPDM (Ethylene propylene) are available upon request.
Interchange:
Coupling:Steel(zinc chromate plating)
Nipple:Hardened steel(zinc chromate plating)
Features:
■Nipples meet or exceed SAE J 1502 and ISO 15171-1 design and performance specification Technical features
■Diagnostic couplings provide easily accessible test points for performance testing of hydraulic and pneumatic systems。
■A safety sleeve lock prevents accidental disconnection. Push-to-connect operation allows one hand operation when connecting the coupling.
■Flush-faced poppet for a minimal air inclusion when connecting ,minimal fluid loss during disconnection and for an easy cleaning.
■NBR (Nitrile) as standard. Other seal materials FKM (VitonTM), EPDM (Ethylene propylene) are available upon request.
Interchange:
派克Parker PD Series
