Pneumatic Quick Couplings > Standard For Oxygen/Fuel Gas Quick couplings
Material:
Socket:chrome-plated Brass
Plug:Hardened chrome-plated steel
Temperature range(NBR):-20°C ~ 80°C
Max.working pressure:16 Bar
Standard and Compatibility:
日东Nitto Kohki Mini super series
Feature:
One-hand operated
The flammable gas socket sleeve ferrule galvanizes red easy to differentiate
Not the oiliness material, ensures the highly effective security
Socket:chrome-plated Brass
Plug:Hardened chrome-plated steel
Temperature range(NBR):-20°C ~ 80°C
Max.working pressure:16 Bar
Standard and Compatibility:
日东Nitto Kohki Mini super series
Feature:
One-hand operated
The flammable gas socket sleeve ferrule galvanizes red easy to differentiate
Not the oiliness material, ensures the highly effective security
