Material:
Body:Brass
Tube supports:Brass
Grippers:Brass
"O"-Ring:Nitrile
Viton/FKM: Alternative as request
Working pressure:250psi/17bar
Temperature range:-40°C to+100°C
Tube OD:1/4",3/8",1/4"Inch 06,08,10,12mm
Thread size:R1/8,R1/4,R3/8,R1/2,N1/8,N1/4,N3/8,N1/2
R=BSPT Conform ISO07    N=NPT Conform SAE AS 71051:1999
D.O.T push-in fittings meet SAE J2494 and D.O.T.FMVSS 571.106 air brake performance requirements.
The series is designed for all D.O.T.truck and trailer applications.
Features:
Brass tube support assures maximum flow and performance characteristics
Positioning elbows and tees are designde only for installation and alignment purpose only.

Application tube:SAE J844 type A&B nylon tubing
